Product Description

• Model Name                 :           AM 405E 2 in 1 Battery Sprayer

• Tank Capacity               :           16 Ltr
• Voltage                         :           DC 12V
• Battery                          :           8AH/10AH
• Flow/Discharge             :           4L/M
• Working Pressure          :           5-6KG/CM2

Features

 (1) The product is consist of fluid tank, bottom, battery, miniature pump,charger, power switch, spray parts (hose, switch, nozzle), belt and soon;

 (2) The container external form is an imatation of human back’s curve. It’s quite comfortable for the users. The design is specific and original;

(3) It uses the miniature diaphragm pump, characteristic, pressure relief automaticly, high pressure and long life. According to different kinds of crops and the spray nozzle, this product can be equipped with pressure regulator to have the right pressure and get the perfect spray mist effects.

Method of Usage

(1) Every time before usage, please insert charger plug into the charger base connector, and get 240V power charger the battery about 3 hours, until the green light is on. Without charging, please do insert plastic into protective cover the charger base it gets damp.

 (2) The mixed medicine should pass through the filter before it goes into the tank, in case the impurities flow into the tank and cause jam in the filter, the pipe and the cylinder and affect the normal use. Cover the cap and tighten it after fill the container full with medicine, in case the medicine overflow when working.

 (3) Please don’t use water-insolube powder. Becasue it will not melt into liquids and suspend in the tank, the solids will gradually settle in the bottom, jam the filter, the pipe and the cylinder and affect the normal use.

 (4) Please wipe it up if the medicine overflows when you increase the medicine; please remove the battery or the electrical device and dry them up with clean cloth if they are exposed to the medicine.

(5) Power switch on the left side, which has two fuctions:“—”means spray; “O”means stop.

(6) Power switch turn to spray“—”, the motor starts and the machine starts working.

 (7) Power switch turn to stop“O” when stop working.

 (8) Recharge the battery timely to guarantee the life of battery
